ขนาด 15 KVA
Technical Parameters
Rated capacity 15KVA
Input phase number 3 Phases
Input voltage 380VAC
Output voltage 220VAC
Working frequency 50/60HZ
Rated current 43 A
Short Circurt Impedance 4%
Voltage Resistance 2500VAc/min (does not have the puncture, no break down)
Insulation Level Level F
Insulation Resistance > 100MΩ/ DC500V
Material Transformer coil adopts 155 degree high temperature copper wire
Silicon steel sheet, Baosteel, B50A470 material
Main material winding Copper
Connection mode △/Y(Can custimized with your requirement)
Environment temperature -10℃ +40℃ ;indoor enclosure, floor-mounted
Temperature rise limit: 100K (Actual temperature minus ambient temperature)
หม้อแปลง 380/400V 3P output 200/220 3P 15 KVA AUTO
- Brand: apple
- Product Code: AVS-380/200-3P-15KVA
- Reward Points: 100
- Availability: In Stock
-
฿16,500.00
- Price in reward points: 400
