ขนาด 20 KVA AUTO 3L + N + G

ลวดทองแดง

Technical Parameters

Rated capacity 20KVA

Input phase number 3 Phases

Input voltage 380VAC

Output voltage 220VAC

Working frequency 50/60HZ

Rated current 52A

Short Circurt Impedance 4%

Voltage Resistance 2500VAc/min (does not have the puncture, no break down)

Insulation Level Level F

Insulation Resistance > 100MΩ/ DC500V

Material Transformer coil adopts 155 degree high temperature copper wire

Silicon steel sheet, Baosteel, B50A470 material

Main material winding Copper

Connection mode /Y(Can custimized with your requirement)

Environment temperature -10 +40 ;indoor enclosure, floor-mounted

Temperature rise limit: 100K (Actual temperature minus ambient temperature)


Write a review

Note: HTML is not translated!
    Bad           Good

หม้อแปลง 380/400V 3P output 200/220 3P 20KVA AUTO

  • Brand: AVS
  • Product Code: AVS-380/200-3P-20KVA
  • Reward Points: 100
  • Availability: In Stock
  • ฿0.00

  • Price in reward points: 400
